Remax 2030 CNC router machine

2030 cnc router machine is used in the wood industry and advertising industry, Suitable for processing wooden furniture, acrylic sheets, aluminum alloys, etc.This machine is equipped with a rotating shaft that can process a variety of cylindrical material

Remax 2030 CNC router machine

Wood cnc router machine used for furniture industries: cabinet doors, wooden doors, solid woods, plates, antique furniture, doors, windows, desks and chairs.

Decoration industries: screens, wave boards, large-size wall hangings, advertising boards and sign making.

1.Import square rail ensure high accuracy and heavy workload.

2.Adopt vacuum system.Made by advanced international technology,with double cavities.

Description	Parameter
X,Y,Z Workiong Area	20003000200mm
X,Y,Z Repositioning Accuracy	±0.03mm
Table Surface	Aluminum
Frame	Welded Structure
X,Y Structure	Rack and Pinion Drive, Hiwin Rail Linear Guide
Z Sturcture	Hiwin Rail Linear Guide And TBI Ball Screw
Max. Power Consumption	(Without Spindle)2.5kw~3kw
Max.Rapid Travel Rate	25000mm/min
Max.Working Speed	18000mm/min
Spidle Speed	4.5 kw
Spindle Power	0-18000RPM
Drive Motors	Servo Motor
Working Voltage	AC380V/50/60Hz,PH(Option:220V)
Command Language	G Code
Operating System	DSP System(Options:Ncstudio/Mach 3 PC Software)
Computer Interface	USB
Flash Memory	128M(U Disk)
Collect	ER25
X,Y Resolution	<0.01mm
Software Compatibility	Type3/UcancameV9 Software,(Option:Artcame Software)
Running Environment Temperature	0-45Centigrade
Relative Humidity	30%-75%
Inverter	Delta/Fuling
Electrical Components	Schneider
Limit Switch	OMRON
Driver	Leadshine or Yako
Warranty	One yeart,expect consumable parts
Support	By calling or Email or trainin

FAQ
Q: This is the first time I use this kind of machine, is it easy to operate?
A: There are english manual or teaching video that show how to use machine.
If there is still have any question, please contact us by e-mail / skype/ phone /trademanager
online service at any time.

Q: If machine have any problem after I receive it, how can I do ?
A: Free parts send to you within machine warranty period if machine have any problem.

Q: MOQ ?
A: The minimum order is 1 set machine, if you order more one time, the price will be better.

Q: How can I buy this machine from you? ( Very easy and flexible !)
A: 1. Consult us about this product on line or by e-mail.
2. Negotiate and confirm the final price , shipping , payment methods and other terms.
3. Send you the proforma invoice and confirm your order.
4. Make the payment according to the method put on proforma invoice.
5. We prepare for your order in terms of the proforma invoice after confirming your full payment.
And 100% quality check before shipping.
6. Send your order by air or by sea.
